3610 - ADA Outdoor Vandal-Resistant Stainless Steel Pedestal Bottle Filler

Technical Downloads

Spec Sheet

Operational / Maintenance Manual

Installation Drawing

Parts Breakdown Drawing

AutoCAD Installation Drawing

3D Revit (RFA)

MasterSpec® Files

Limited Warranty

Brochures

Specifications

Model 3610 ADA vandal-resistant outdoor, pedestal bottle filler shall include a heavy duty stainless-steel pedestal with matte silver powder-coating, vandal-resistant push-button operated stainless steel valve with front-accessible cartridge and flow adjustment, large-opening bottle filler with quick-fill 1 gpm flow rate, 100% lead-free waterways, vandal-resistant access plates, integral mounting feet, and 1-1/2" slip waste. In extreme environments related to heat and cold, product(s) must be protected from damage/exposure due to these extreme conditions.

Pricing Information

$6539 USD
Contact Haws Specials

ADA Outdoor Vandal-Resistant Stainless Steel Pedestal Bottle Filler

The Haws 3610 ADA heavy-duty vandal-resistant outdoor pedestal bottle filler can be configured in multiple variations before or after installation. This model is standard with a single bottle filler, and the option of adding/changing a drinking fountain, bottle filler, dog bowl and/or hose bib at any time. It incorporates the 'only' all stainless-steel valve body that is machined out of solid bar stock, is fully serviceable through the front of the push button assembly offering access to the water control cartridge and integral water supply strainer, and has front access to the water stream height adjustment for easy maintenance without having to remove the valve. Equipped with vandal resistant components for long lasting durability.

Only stainless steel valve body that is machined out of solid bar stock
Heavy-duty fabricated stainless steel with matte silver powder-coated finish
Vandal resistant components include the bottle filler nozzle, button, and access plates
Modular design allows options and accessories to be added or removed at any time
Custom color options available
Large-opening bottle filler with quick-fill 1 gpm flow rate
Easy maintenance with front access to valve adjustment and cartridge replacement
100% lead-free waterways

Model meets all current Federal Regulations for the disabled including those in the Americans with Disabilities Act. Haws manufactures drinking fountains, faucets and electric water coolers to be lead-free by all known definitions including NSF/ANSI/CAN 61- Section 9, NSF/ANSI/CAN 372, California Proposition 65, and the Federal Safe Drinking Water Act. Product is compliant to California Health and Safety Code 116875 (AB 1953-2006), and 116876 (AB 100) "NSF/ANSI/CAN 61: Q ≤ 1".

Prop 65 Warning. For California Residents Warning: This product contains a chemical known to the State of California to cause cancer and/or birth defects or other reproductive harm. Please click here for more information.
