3377 - ADA Vandal-Resistant Outdoor Steel Pedestal Fountain

Home / Products / 3377 – ADA Vandal-Resistant Outdoor Steel Pedestal Fountain

Technical Downloads

Spec Sheet

Installation Drawing

Parts Breakdown Drawing

Operational / Maintenance Manual

Operational / Maintenance Manual French

AutoCAD Installation Drawing

MasterSpec® Files

Limited Warranty

Specifications

Model 3377 ADA vandal-resistant pedestal drinking fountain shall include an 18 gauge Type 304 Stainless Steel satin finish basin with integral swirl design, 14 gauge Type 304 Stainless Steel bracket, 100% lead-free waterways, vandal-resistant push-button operated stainless steel valve with front-accessible cartridge and flow adjustment, polished chrome-plated brass vandal-resistant bubbler head with integral laminar anti-squirt flow, chrome-plated brass vandal-resistant waste strainer, vandal-resistant bottom plate, 3/16" galvanized steel top-access pedestal with green powder-coated finish, integral mounting plate, and 1-1/4" IPS waste.

Pricing Information

$3676 USD
Contact Haws Specials

ADA Vandal-Resistant Outdoor Steel Pedestal Fountain

The Haws 3377 ADA outdoor vandal-resistant powder-coated green pedestal and stainless steel fountain incorporates a patented stainless steel push-button valve assembly allowing for front access stream adjustment as well as cartridge and strainer access. This pedestal mounted fountain offers the 'only' all stainless-steel valve body that is machined out of solid bar stock, is fully serviceable through the front of the push button assembly offering access to the water control cartridge and integral water supply strainer, and has front access to the water stream height adjustment for easy maintenance without having to remove the valve. Equipped with vandal resistant components, this fountain is not easily disrupted, quickly discouraging the worst of vandals.

Only stainless steel valve body that is machined out of solid bar stock
14 gauge stainless steel bracket and 3/16" galvanized steel pedestal with green powder-coated finish provides an exceptional corrosion resistance
Vandal resistant components include the bubbler, button, bowl, drain and bottom/access plates
100% lead-free waterways
Easy maintenance with front access to valve adjustment and cartridge replacement
Laminar flow prevents from splashing, keeping the drinking water contained and area clean

Model meets all current Federal Regulations for the disabled including those in the Americans with Disabilities Act. Haws manufactures drinking fountains, faucets and electric water coolers to be lead-free by all known definitions including NSF/ANSI/CAN 61- Section 9, NSF/ANSI/CAN 372, California Proposition 65, and the Federal Safe Drinking Water Act. Product is compliant to California Health and Safety Code 116875 (AB 1953-2006), and 116876 (AB 100) "NSF/ANSI/CAN 61: Q ≤ 1".
