1920WHO

Vandal-Resistant Motion-Activated White Bottle Filler

Model 1920WHO vandal-resistant wall-mounted touchless white powder-coated bottle filling station. (For mounting bottle filler, see options below) FOR INDOOR USE ONLY

Spec Sheet Download

Spec Sheet

Operational / Maintenance Manual

Installation Drawing

Parts Breakdown Drawing

AutoCAD Installation Drawing

Limited Warranty

View All Resources

Specifications

Model 1920WHO motion-activated wall mounted vandal-resistant bottle filler shall include 100% lead-free waterways, white powder coated stainless-steel construction, vandal-resistant sensor operated stainless steel solenoid valve with 30-second obstruction time-out controlled by a transformer, 1 gpm (3.78 L) laminar flow, and vandal-resistant bottom plate. It can be used as a stand-alone station or mounted above the Haws® 1311 or 1501 series drinking fountains.

Pricing Information

$901 USD
Contact Haws Specials

Vandal-Resistant Motion-Activated White Bottle Filler

Model 1920WHO vandal-resistant touchless stainless-steel bottle filler powder-coated white uses a sensor operated stainless steel solenoid valve controlled by a transformer for hands-free operation. A pressure regulator is used to adjust the flow according to incoming water pressures. It can be a stand-alone station, or mounted above the Haws 1311 or 1501 series drinking fountains.

Touchless operation for safety and peace of mind
Vandal resistant components include the sensor casing and bottom plate
100% lead-free waterways
30-second obstruction time-out to reduce tampering of sensor
Gloss white powder-coated finish
Available steel wall mounting plate recommended
1 gpm (3.78 L) Laminar flow

Haws manufactures drinking fountains, faucets and electric water coolers to be lead-free by all known definitions including NSF/ANSI/CAN 61- Section 9, NSF/ANSI/CAN 372, California Proposition 65, and the Federal Safe Drinking Water Act. Product is compliant to California Health and Safety Code 116875 (AB 1953-2006), and NSF/ANSI/CAN 61: Q ≤ 1.
