1311S

ADA Vandal-Resistant White Enameled Iron Fountain and Motion-Activated Bottle Filler Bundle

Model 1311S, ADA wall mounted vandal-resistant, white enameled-iron fountain and white powder-coated touchless bottle filler. FOR INDOOR USE ONLY
Product Includes:

1311: Fountain
1920WHO: Bottle Filler
BP8W:Fountain Back Panel
BP15W: Bottle Filler Back Panel
6700 (x2): In-Wall Mounting Plates

Operational / Maintenance Manual

Spec Sheet & Installation Drawing

MasterSpec® Files

Limited Warranty

Specifications

Model 1311S wall mounted vandal-resistant ADA drinking fountain and motion-activated bottle filler shall include a white enameled-iron basin with 14 gauge Type 304 powder-coated Stainless Steel bottle filler bracket, 100% lead-free waterways, sensor operated solenoid valve with 30-second obstruction time-out on the bottle filler which incorporates an in-wall 3/16" thick steel mounting plate, and vandal-resistant push-button operated stainless-steel valve with front-accessible cartridge and flow adjustment on the fountain, polished chrome-plated brass vandal-resistant bubbler head with integral anti-squirt flow, 1 gpm (3.78 L) laminar flow bottle filler, chrome plated brass vandal-resistant waste strainer, vandal-resistant bottom plates, and a 1-1/4" NPT trap. FOR INDOOR USE ONLY

Touchless sensor upgrades available—call Customer Service at (888) 640-4297:
First sensor +$331

Pricing Information

$3690 USD
Contact Haws Specials

ADA Vandal-Resistant White Enameled Iron Fountain and Motion-Activated Bottle Filler Bundle

The Haws 1311S ADA vandal-resistant drinking fountain and touchless bottle filler incorporates a sensor operated stainless steel solenoid valve controlled by a transformer for hands-free operation on the bottle filler, and offers the ‘only’ all stainless-steel valve body that is machined out of solid bar stock on the fountain. It is fully serviceable through the front of the push button assembly offering access to the water control cartridge and integral water supply strainer and has front access to the water stream height adjustment for easy maintenance without having to remove the valve.

Optional 3000 gallon water filter available (model 6480)
Only stainless steel valve body that is machined out of solid bar stock
100% lead-free waterways
Vandal resistant components include the bubbler, button, drain and bottom plates
30-second obstruction time-out to reduce tampering of sensor
White enameled-iron fountain design provides toughness for the worst of environments
1 gpm (3.78 L) bottle filler laminar flow
Easy maintenance with front access to valve adjustment and cartridge replacement
Beautiful white enamel fountain and powder-coated bottle filler combination brings pleasing aesthetics to any environment
Soft rounded corners prevent from mishaps and other accidents that may occur once the fountain is installed

Model meets all current Federal Regulations for the disabled including those in the Americans with Disabilities Act. Haws manufactures drinking fountains, faucets and electric water coolers to be lead-free by all known definitions including NSF/ANSI/CAN 61- Section 9, NSF/ANSI/CAN 372, California Proposition 65, and the Federal Safe Drinking Water Act. Product is compliant to California Health and Safety Code 116875 (AB 1953-2006), and 116876 (AB 100) "NSF/ANSI/CAN 61: Q ≤ 1". Product Includes:

1311: Fountain
1920WHO: Bottle Filler
BP8W:Fountain Back Panel
BP15W: Bottle Filler Back Panel
6700 (x2): In-Wall Mounting Plates
