3202 - ADA Outdoor Steel Pedestal Fountain

Home / Products / 3202 – ADA Outdoor Steel Pedestal Fountain

Technical Downloads

Spec Sheet

Installation Drawing

Parts Breakdown Drawing

Operational / Maintenance Manual

AutoCAD Installation Drawing

3D Revit (RFA)

MasterSpec® Files

Limited Warranty

Specifications

Model 3202 ADA pedestal drinking fountain shall include a 12 gauge galvanized substrate steel pedestal with green powder coating, push-button operated stainless steel valve with front-accessible cartridge and flow adjustment, 100% lead-free waterways, polished chrome-plated brass vandal-resistant bubbler head backed against a pedestal guard, trough design in the pedestal instead of a waste to eliminate clogging, a 1/4" (.6 cm) spacer to raise the pedestal off the ground which reduces the potential for corrosion, integral mounting feet, and an over-size vandal-resistant access plate. In extreme environments related to heat and cold, product(s) must be protected from damage/exposure due to these extreme conditions.

ADA Outdoor Steel Pedestal Fountain

Haws heavy-duty pedestal drinking fountains, like the 3202, use a patented push-button stainless steel valve assembly allowing for front access stream adjustment as well as cartridge and strainer access. This pedestal mounted fountain offers the 'only' all stainless-steel valve body that is machined out of solid bar stock, is fully serviceable through the front of the push button assembly offering access to the water control cartridge and integral water supply strainer, and has front access to the water stream height adjustment for easy maintenance without having to remove the valve. The angled barrier-free, trough style design of the 3202 allows the square pedestal to be placed securely in multiple locations where a gravel fill is present or can be installed. Gravel fill and trough design completely eliminate the need for traditional drains that can be clogged with sand and other contaminates. Fountain comes further equipped with multiple vandal resistant components, making it uneasily disrupted, quickly discouraging the worst of vandals.

Only stainless steel valve body that is machined out of solid bar stock
Heavy-duty 12 gauge fabricated galvanized steel; with green powder-coated finish provide an exceptional corrosion resistance in one tough built fountain
100% lead free waterways
Easy maintenance with front access to valve adjustment and cartridge replacement
Welded heavy-duty bubbler guard protects the drinking point from misuse
Large access panel allows for a comfortable fit when adjusting components or when maintenance is needed

Model meets all current Federal Regulations for the disabled including those in the Americans with Disabilities Act. Haws manufactures drinking fountains, faucets and electric water coolers to be lead-free by all known definitions including NSF/ANSI/CAN 61- Section 9, NSF/ANSI/CAN 372, California Proposition 65, and the Federal Safe Drinking Water Act. Product is compliant to California Health and Safety Code 116875 (AB 1953-2006), and 116876 (AB 100) "NSF/ANSI/CAN 61: Q ≤ 1".
