1430-1920W

Vandal-Resistant Enameled Iron Fountain and Bottle Filler

Model 1430-1920W, wall mounted vandal-resistant, white enameled iron two bubbler drinking fountain and bottle filler. The bottle filler requires a mounting plate; either the 6700 in-wall or the 6700R on-wall support plate. (See options below)

Spec Sheet Download

Required Parts Sold Separately

1430
1920W

Spec Sheet

MasterSpec® Files

Limited Warranty

Specifications

Model 1430-1920W wall mounted vandal-resistant drinking fountain and bottle filler shall include a white enameled-iron basin mounted with twin galvanized cast-iron wall brackets, vandal-resistant push-button operated stainless steel valves with front-accessible cartridge and flow adjustment, 100% lead-free waterways, 1 gpm (3.78 L) bottle filler laminar flow, dual polished chrome-plated brass vandal-resistant bubbler heads, polished chrome-plated brass vandal-resistant waste strainer, vandal-resistant bottom plate, and chrome-plated 1-1/2" NPT trap. The botte filler requires a mounting plate; either the Haws model 6700 in-wall or the 6700R on-wall support plate.

Pricing Information

$3719 USD
Contact Haws Specials

Vandal-Resistant Enameled Iron Fountain and Bottle Filler

The multi-bubbler Haws 1430-1920W vandal-resistant enameled iron drinking fountain and bottle filler uses patented stainless steel, push-button activated, valve assemblies allowing for front access stream adjustments as well as cartridge and strainer access. This wall mounted fountain offers the 'only' all stainless-steel valve body that is machined out of solid bar stock, is fully serviceable through the front of the push button assembly offering access to the water control cartridge and integral water supply strainer, and has front access to the water stream height adjustment for easy maintenance without having to remove the valve. Equipped with vandal resistant components, this fountain is not easily disrupted, quickly discouraging vandals.

Only stainless steel valve body that is machined out of solid bar stock
100% lead-free waterways
Vandal resistant components include the bubblers, buttons, drain and bottom plate
Gleaming white enameled iron construction provides this fountain with a bullet proof durability hidden beneath its elegant appeal
1 gpm (3.78 L) bottle filler laminar flow
Easy maintenance with front access to valve adjustment and cartridge replacement
Soft rounded corners prevent mishaps and other accidents that may occur once the fountain is installed
Dual bubbler heads locked to main bowl deter vandals and provide efficient water flow for twice the users as single bubbler fountains
The bottle filler requires a mounting plate; either the 6700 in-wall or the 6700R on-wall support plate. (See options below)

Haws manufactures drinking fountains, faucets and electric water coolers to be lead-free by all known definitions including NSF/ANSI/CAN 61- Section 9, NSF/ANSI/CAN 372, California Proposition 65, and the Federal Safe Drinking Water Act. Product is compliant to California Health and Safety Code 116875 (AB 1953-2006), and 116876 (AB 100) "NSF/ANSI/CAN 61: Q ≤ 1".

Note: Enameled iron bowls are shipped without the hardware mounted. Hardware to be mounted by installer.
