Tempered, Gravity-Fed, Portable Eyewash

Model 7501T, 9-gallon (34 L), gravity-fed, tempered portable eyewash that uses a heated, insulated blanket to provide ANSI compliant tempered potable water in operating temperatures between -20° F (-30° C) and 100° F (38° C). Ideal for remote locations without access to continuous potable water.

Spec Sheet Download

Technical Downloads

Spec Sheet

Spec Sheet French

Installation Drawing

Parts Breakdown Drawing

Operational / Maintenance Manual

AutoCAD Installation Drawing

MasterSpec® Files

Limited Warranty

Specifications

Model 7501T is a 9-gallon (34 L), tempered, compact gravity-fed portable eyewash with a NEMA 3R heated, insulated blanket to provide ANSI compliant tempered potable water in ambient operating temperatures to -20° F (-30° C) and 100° F (38° C). Ideal for remote locations without access to continuous potable water. 120VAC, 60Hz, 1.38A electrical requirement with supplied 8' GFCI power cord. The unit includes a FDA approved high-density green polyethylene tank, ABS plastic eyewash heads with .4 gpm (1.5 L) flow rate over 15 minutes, yellow pull-down activation arm, integral handle with 'lift here' graphics on top, clearly visible fill line, wide-fill threaded cap, sign-mounted operating instructions, and stainless steel wall bracket (unit must be hung). QPS-C-US-Certified-Electrical-Safety. Voltage and Haz Loc options available. Model 9082 additive not included - order separately.

Pricing Information

$2922 USD
Contact Haws Specials

Tempered, Gravity-Fed, Portable Eyewash

The newly retooled Haws 7501T compact portable tempered eyewash ideal for remote locations. The 9-gallon (34 L), gravity-fed, eyewash uses a heated, insulated blanket to provide ANSI compliant tempered potable water in operating temperatures between -20° F (-30° C) and 100° F (38° C) for locations without access to a continuous potable water source. 120VAC, 60Hz, 1.38A electrical requirement with supplied 8' power cord. This unit is a cost-effective solution ideal for locations without access to potable water, including temporary decontamination sites, temporary treatment facilities, and short-term job sites.

A wide-fill opening with a securely threaded cap, and a pronounced "Max Fill" line that permits easy inspection, cleaning and filling
FDA approved high-density green polyethylene tank that is easily activated by pulling the yellow activation arm down to the open position
Ease of relocation due to "Lift Here" graphics, easily mounted bracket (included) and light design
Measurements: 16" high, 24" wide, 12" deep (36.8 x 55.9 x 25.7 cm). *Note: Unit must be wall hung

QPS-C-US-Certified-Electrical-Safety for NEMA/Type 3R in ordinary locations, and to ANSI/ISEA Z358.1 Standard for Emergency Eyewash and Shower Equipment, which is clearly called out on the exterior of the unit.
