Drinking Faucet

Model 5010.6427SS, polished stainless steel push button bubbler valve with socket flange intended for a counter top or sink mounting.

Spec Sheet Download

Technical Downloads

Spec Sheet

Installation Drawing

Parts Breakdown Drawing

Operational / Maintenance Manual

AutoCAD Installation Drawing

Specifications

Model 5010.6427SS deck or sink mounted bubbler valve shall include a stainless steel push button bubbler valve with a polished finish, integral stream flow regulation, brushed stainless steel deck flange, and 3/8" IPS inlet. In extreme environments related to heat and cold, product(s) must be protected from damage/exposure due to these extreme conditions.

Pricing Information

$452 USD
Contact Haws Specials

Drinking Faucet

Model 5010.6427SS push button bubbler valve is designed with an adjustable stream regulation and a shielded bubbler to provide an anti-squirt drinking stream. Unit is self contained and is constructed from stainless steel with a polished finish, making this bubbler valve resistant to corrosive materials, and is easy to keep clean.

Bubbler head includes: socket flange locked to bubbler inlet, washers, and locknut
Dimensions: Flange diameter is 2-1/8" (5.4 cm), shank is 7/8" (2.2 cm) diameter x 1-1/8" (3.2 cm) long, and connection is a 3/8" IPS inlet
Haws manufactures drinking fountains, faucets and electric water coolers to be lead-free by all known definitions including NSF/ANSI/CAN 61- Section 9, NSF/ANSI/CAN 372, California Proposition 65, and the Federal Safe Drinking Water Act. Product is compliant to California Health and Safety Code 116875 (AB 1953-2006), and NSF/ANSI/CAN 61: Q ≤ 1.
