1119FRP

ADA Outdoor Freeze-Resistant Vandal-Resistant Dual Drinking Fountain and Bottle Filler

Model 1119FRP, freeze-resistant, hi-lo ADA, wall mounted dual vandal-resistant, stainless-steel drinking fountain with bottle filler and freeze valves.
Product Includes:

1119FR Hi-Lo Fountains and Back Panel
1920 Bottle Filler, 6469 Drip Tray and Back Panel
6521FR Freeze Resistant In-Wall Valve x3
6700.4 In Wall Mounting Plate
6700 In Wall Mounting Plate

Spec Sheet & Installation Drawing

Operational / Maintenance Manual

3D Revit (RFA)

MasterSpec® Files

Limited Warranty

Specifications

Model 1119FRP Hi-Lo wall mounted vandal-resistant barrier-free freeze-resistant drinking fountain and bottle filler shall include dual 18 gauge Type 304 Stainless Steel satin finish basins, 14 gauge Type 304 Stainless Steel bottle filler bracket, In-wall 3/16" thick steel mounting plates add extra wall support when mounting the fountains and bottle filler, polished chrome-plated brass vandal-resistant bubbler heads, 1 gpm (3.78 L) laminar flow bottle filler, polished chrome-plated brass push-buttons which operate pneumatic valves housed in insulated cabinets, installed on the inside wall where room temperatures do not drop below 50° F (10° C), self-draining water lines protect the unit from freezing, polished chrome-plated brass vandal-resistant waste strainers, stainless steel satin finish back panels, high and low fountain mounting levels, and 1-1/4" O.D. waste pipes. The botte filler requires a mounting plate; either the Haws model 6700 in-wall or the 6700R on-wall support plate. In extreme environments related to heat and cold, product(s) must be protected from damage/exposure due to these extreme conditions.

Pricing Information

$6813 USD
Contact Haws Specials

ADA Outdoor Freeze-Resistant Vandal-Resistant Dual Drinking Fountain and Bottle Filler

The Haws 1119FRP barrier-free Hi-Lo vandal-resistant drinking fountain and bottle filler incorporates fully engineered pneumatic operated freeze-resistant valve assemblies. Wall mounted design allows the 1119FR to be placed securely in multiple locations without taking up excess space. Equipped with vandal resistant components, this fountain is not easily disrupted, quickly discouraging vandals.

18 gauge Type 304 Stainless Steel design provides a well constructed sturdy fountain
Vandal resistant components include the bubblers, buttons, drains and bottom plates
In-wall 3/16" thick steel mounting plates add extra wall support when mounting the fountains and bottle filler
Valves are installed in an area where the temperature remains at a minimum of 50° F (10° C) so the fountain remains fully functional in freezing conditions
Drip tray for bottle placement during filling
1 gpm (3.78 L) laminar flow bottle filler
Beautiful satin finish resists stains and corrosion
Soft rounded corners prevent mishaps and other accidents that may occur once the fountain is installed
"Hi-Lo" design allows for twice the users as regular fountains and suits the needs for various user heights
One-piece stamped bowls make for an aesthetically pleasing and durable design

Model meets all current Federal Regulations for the disabled including those in the Americans with Disabilities Act. Haws manufactures drinking fountains and electric water coolers to be lead-free by all known definitions including NSF/ANSI Standard 61, Section 9, California Proposition 65, and the Federal Safe Drinking Water Act. Product is compliant to California Health and Safety Code 116875 (AB 1953-2006), and 116876 (AB 100) "NSF/ANSI/CAN 61: Q ≤ 1".
