8356WCSM

Barrier-Free Ceiling-Mounted Shower and Surface-Mounted Eye/Face Wash w/Drain Pan

Model 8356WCSM, surface mounted combination shower and eye/face wash with AXION® MSR eye/face wash head and ceiling-mounted showerhead, along with a drain pan.

Spec Sheet Download

Technical Downloads

Specifications

Model 8356WCSM wheelchair accessible surface-mounted combination shower and eye/face wash shall include an AXION® MSR eye/face wash head shall feature inverted directional laminar flow which achieves Zero Vertical Velocity™ supplied by an integral 4.2 gpm flow control. Unit shall also include the AXION MSR hydrodynamic design stainless steel showerhead with 20 gpm flow control, a surface-mounted wall mounted 18 Gauge, Type 304 stainless steel deep-drawn electro-polished cabinet, stainless steel surface-mount support enclosure, and polished chrome-plated brass pull-down eye/face wash valve with easy access in-line strainer. Unit shall also include stainless steel pipe and fittings, 1" brass shower ball valve, a drain pan, a front-access maintenance panel, universal sign, 1" NPT(F) inlet and 2" NPT(F) drain. Operating pressure is 30 - 90 psi (2.1 - 6.2 bar).

Pricing Information
